Features
- High-precision DC resistance measurement (± 0.2% accuracy)
- Multiple test current options (1 mA to 50 A)
- Dual-channel simultaneous measurement capability
- 128×64 dot matrix LCD display
- Built-in thermal printer for instant results
- Automatic calibration and self-check functions
- Intelligent power management system
- Multi-range measurement (1 μΩ to 20 kΩ)
- AC or DC dual power supply (220 V or 12 V)
- Data storage for 255 test results
- Optional remote control and USB or RS232 interfaces
Technical Specifications
| Test Current Range | 1 mA to 50 A (multiple selectable ranges) |
| Measurement Range | 1 μΩ to 20 kΩ |
| Accuracy | ± 0.2% of full scale |
| Resolution | 0.1 μΩ to 1 μΩ |
| Display | 128×64 matrix LCD |
| Channels | Single, dual and triple channel options |
| Power Supply | AC 220V ± 10% or DC 12V |
| Data Storage | 255 test records |
| Printer | Built-in thermal printer |
| Interfaces | Optional USB, RS232 |
| Operating Temperature | 32 °F to 104 °F (0 °C to 40 °C) |
| Dimensions | 15.7 in × 11.8 in × 9.8 in (40 cm × 30 cm × 25 cm) |
| Weight | 2.205 lb (1kg) |
