Features
- IP65 standard, with the durable shell (oil-proof, water-proof and dust-proof)
- PC software is available for data analysis, management and reports printing
- Probe automatic calibration
- DAC and AVG are automatically formed, and can be corrected and compensated
- Freely switch to four kinds of standards (depth D, level P, distance S, amplitude H)
- Functions such as Auto-gain and peak memory improve detection efficiency
- Automatically calculate the φ value equivalent defects
- 13 built-in testing standards are available
- Storage: 500-1000 pieces of A-scan images and data
- Power supply: rechargeable Li-ion battery, standby time more than 15hours
- The width and intensity of launch pulse are adjustable
- AWS standards are available
- With measuring video function
Technical Specifications
| EMSUFD-221(A) | EMSUFD-221(B) | |
| Operating Frequency | 0.5MHz to 20MHz | |
| Scan Range(mm) | 0 to 6000mm | 0 to 10000mm |
| Velocity Range（m/s） | 1000 to 15000 | 100 to 20000 |
| Vertical linearity error | ≤3% | ≤2% |
| Dynamic Range | ≥32dB | ≥35dB |
| Horizontal linearity error | ≤0.2% | ≤0.1% |
| Testing sensitivity | ≥62dB (Depth 200mm, Φ2 flat bottom hole) | ≥65dB (Depth 200mm, Φ2 flat bottom hole) |
| Measuring channel | 100 | 500 |
| Storage | 500 | 1000 |
| TCG curve | ○ | ● |
| B Scan | ○ | ● |
| PC Connection | ● | |
| Gain Range(dB) | 0 dB to 110dB | 0 dB to 130dB |
| AWS | ○ | ● |
| Standard Probes | Straight probe: 2.5MHz, diameter 20mm, cable Q9-Q9 Angle probe: 4MHz, 60 degree, 8 mm x 9 mm, cable Q9-C5 | |
| Dimension | 9.45 in × 7.28 in × 2.17 in (24 cm ×18.5 cm × 5.5 cm) | |
| Weight | 4.08 lb s(1.85 kg) | |
