Technical Specifications
| Specification | Details |
| Rotation Speed Range for Dynamic Balancing | 70-13,000 r/min |
| Range Selection | Auto-range and manual-range selectable |
| Vibration Accuracy | 5% |
| Sensors | Piezoelectric accelerometer, Magnetoelectric velocity, Eddy displacement, etc. |
| Filters | 8th-order ellipse anti-aliasing filter, RPM band-pass filter |
| Input Signal | Accelerometer, ICP, and voltage |
| Frequency Span of Spectrum Analysis | 100, 200, 500, 1K, 2K, 5K, 10K, 20K, 35KHz (varies with sampling channels) |
| Single-Channel Sampling Frequency | 89.6KHz (Spectrum analysis: 35KHz) |
| Dual-Channel Sampling Frequency | 51.2KHz (Spectrum analysis: 20KHz) |
| Data Storage | 8G |
