Features
- Automatic integration to realize one-button measurement function;
- Treat 4 samples at a time;
- HD video instead of the traditional microscope, high visual inspection;
- Automatic recording of melting process, initial melting, final melting;
- Data can be printed directly through the printer;
- Meet 21CFR Part 11, audit tracking, pharmacopoeia and electronic signature;
- Compliance with the GLP requirement specification.
Applications
- Chemical industry
- pharmaceutical research
- production of food
- Necessary instrument for drugs, spices, dyes and other organiccrystal substances.
Technical Specifications
| Specification | Details |
| Temperature Range | Room Temperature – 360℃ |
| Detection Method | Fully Automatic (Compliant Manual Mode) |
| Processing Capacity | 4 Samples/Batch (Simultaneous Testing) |
| Temperature Resolution | 0.01℃ |
| Heating Rate | 0.1℃–20℃ (200 Gears Adjustable) |
| Temperature Control Mode | PID Precise Control, Fully Sealed Furnace Body |
| Heating Method | Conduction Liquid Heating or Electric Heating Block Air Heating (Optional) |
| Temperature Increase Accuracy | 0.1℃ |
| Accuracy | ±0.3℃ (<200℃), ±0.5℃ (>200℃) |
| Correction Function | Yes |
| Exploration Mode | Yes |
| Video Function | Photo-Taking and Camera-Shooting |
| Video Replay | Yes, with Time Watermark |
| HD Camera | Observe Sample Melting State |
| Magnification | 20X |
| User Management | >360 Users, Four Levels of Management |
| Storage Space | 32GB Hard Disk, 2GB Memory |
| Test Method | Yes |
| Data Preservation | Yes |
| Graph Preservation Number | 300 Sets |
| Video Preservation | Yes |
| Continuous Video Shooting Time | 50 Minutes |
| Memory Expansion | Yes |
| Experimental Method Storage | 300 Sets |
| Audit Tracking | Yes |
| Display Mode | 8-Inch HD Color Screen |
| Data Interface | USB, Network Wi-Fi, RS232 |
| Data Authenticity | Tamper-Proof Function |
| Data Download | U-Disk |
| Data Download Format | PDF or Excel |
| Data Overflow Reminder | Automatic Reminder in Advance |
| Printer | Optional (Laser/Thermal/Needle Printer) |
| Capillary Size | Outer Diameter (Details Not Provided) |
| Power Supply | 220V, 50Hz |
