Features
- Charging or Start Circuit Tests Support 12 V & 24 V
- Various Sensor Tests Supports testing of ABS, Accelerator
- Fast and Easy
- Support various Actuator tests: multiple fuel injector voltages and currents
- fan control signals, variable valve timing
- Ignition Including Primary ignition, Secondary ignition
- CAN High or CAN Low, CAN FD, LIN, Flex Ray, and K line
- Combination Tests Multiple channels of oscilloscope
Technical Specifications
| Analog Channels | 4 |
| Bandwidth | 200 MHz |
| Sample Rate | 2 GSa/S |
| Memory Depth | 220 Mpts |
| Waveform Capture Rate | 300,000 wfms/s |
| Support Test | Charging & Start Circuit etc |
| Bandwidth Filter | 20 MHz, Low Pass (to 30 Hz) |
| Interfaces | Wi-fi, USB 3.0 or 2.0 Host, USB Type-C, Grounding, HDMI, Trigger out |
| Display | Wi-Fi, USB 3.0 or 2.0 Host, USB Type-C, Grounding, HDMI, Trigger out |
| Battery | 7.4 V, 7500 mAh, Li-ion battery |
| Operating Method | All touch |
| Size | 10.43 in x 7.55 in x 1.9 in (265 mm x 192 mm x 50 mm) |
| Weight | 4.18 lb (1.9 Kg) |
