Features
- Portable only 2.75 lb (1.25 kg)
- High power 250 A high current output
- Simple UI design
- Data transmission by handset software
- Longest optional 15 m test wire
Technical Specifications
| Battery | Type: 5600 mAh Li- Po (User-replaceable)Voltage: 37 V
Recharge time: 2 hrs |
| Memory | Internal: 2 GB SD cardStore up to 1000 measurements |
| AC Adapter | Input voltage: 90 V to 264 V AC, 50 Hz/60 HzOutput voltage: 12 V DC
Output current: 3 A |
| Interface | Bluetooth, connect the device and PC |
| Output Data (Non-Loaded) | Test current range: up to 250 A DC (adjustable)Maximum output voltage: 4.1 V DC |
| Real Time Clock (Non-Battery) | Accuracy: ± 5 seconds per monthCalendar: 100 leap year detection
Retention time: more than 10 years |
| Environment Conditions | Operating temperature14 ºF to 131 ºF (-10 ºC to 55 ºC)
Storage & transportation temperature -40 ºF to 158 ºF (-40 ºC to +70 ºC) Humidity 5 % to 95 % relative humidity |
