Features
- LF-Touch-OS software system
- Multiple working modes
- Precision micro step control technology
- Wizard flow calibrating function
- The operating expert system
- RS485 communication interface
- Intelligent temperature-control technology
- Super anti-interference
- 304 stainless steel shell
Technical Specifications
| Flow range | 0.00011 mL / min to 1650 mL / min |
| Speed range | 0.1 rpm to 150 rpm |
| Speed resolution | 0.1 rpm |
| Dispensing volume | 0.01 μl to 9999 μl
(It is recommended to have a minimum fill of 50 μl.) |
| Dispensing interval time | 0.1 S / Min / H to 999.9 S / Min / H, time unit adjustable |
| Power consumption | ＜60 W |
| Communication interface | RS485 communication interface, Modbus protocol is available |
| Speed accuracy | ＜ ± 0.2 % |
| Dispensing time | 1 to 999, “0” Infinite cycle |
| Power supply | AC 100 V to 240 V, 50 Hz / 60 Hz |
| External control | Input level 5 V, 12 V (standard), 24 V (optional) |
| External control analog | 0 V to 5 V (standard), 0 V to 10 V, 4 mA to 20 mA (optional) |
| Working environment | Temperature 0 °F to 104 °F (0 ℃ to 40 ℃), relative humidity＜80 % |
| IP grade | IP 31 |
| Dimension(L×W×H) | 11.3 in x 5.90 in x 9.33 in
(28.7 cm x 14.9 cm x 23.6 cm) |
| Weight | 11.45 lb (5.2 kg) |
