Features
- Great Hardware: with a 3.6 in (45 mm) large LCD screen
- 3800 mAh capacity battery pack
- Its duration time is 6 hrs to 8 hrs, which enables longer outdoor operation time
- ALL BANDS COVERING With a built-in power output of 5 W
- Besides, it also comes with a trestle for desktop operation
- IF OUTPUT With IF signal output (1 IF: 70.455 MHz, 2 IF: 10.695 MHz, 3 IF 455 kHz (FM))
- PORTABLE SIZE: Very small in size and ultra-portable
- Built in ATU, Built in AF-DSP
Technical Specifications
| Talk Range | 40 mi (60 km) |
| Private Mold | NO |
| Frequency Range | 0.5 MHz to 30 MHz, 50 MHz to 54 MHz |
| Power Supply | 9.0 V DC to 15.0 V DC |
| Receiving Current | 500 mA Max |
| Operating Modes | A1A, A3E, J3E, F3E |
| Transmitting Frequency Range | 1.8 MHZ to 54 MHz (Amateur band only) |
| Working Mode | SSB / CW / AM / FM / RTTY / PSK |
| FM Maximum frequency swing | ±5 kHz |
| Spur Reduction | -45 dB |
| Carriers Suppression | >40 dB |
| Sideband Spurious | >50 dB |
| SSB Frequency Response | 400 Hz to 2800 Hz (-6 dB) |
| Microphone Impedance | 200 to 10 k Ω (conventional 600 Ω) |
| Antenna Tuner Storage | Store one point every 100 kHz interval |
| First Tuning Time for Antenna Tuner | ≤10s |
| Read Tuning | ≤2s |
| Operating Temperature Range | 14 °F to 140 °F (-10 ℃ to +60 ℃) |
| Dimensions | 0.6 in x 0.3 in x 0.1 in (17 mm x 9.5 mm x 5 mm) |
