Features
- High-speed 10G data transmission
- Operates at wavelengths of 1270/1330nm
- Single LC fiber connector for compact design
- Supports transmission distances up to 20 km (12.43 mi)
- Digital Diagnostic Monitoring (DOM) supported
- Power consumption below 1.5W for efficiency
- Operates on a single +3.3V power supply
- Stable operation in 32 to 158 °F (0 to 70 °C)
- Hot-pluggable SFP+ form factor for easy deployment
- Compliant with IEEE 802.3 and SFP+ MSA standards
Technical Specifications
| Specification | Details |
| Product Type | Fiber Optic Transceiver |
| Form Factor | SFP+ |
| Maximum Data Rate | 10 Gbps |
| Wavelength | 1270/1330 nm |
| Connector Type | Single LC |
| Media Type | Single-Mode Fiber (SMF) |
| Maximum Distance | 12.43 mi (20 km) |
| Power Supply | +3.3V |
| Power Consumption | < 1.5W |
| Digital Diagnostic Monitoring (DDM) | Supported |
| Extinction Ratio | 9 dB |
| Operating Temperature | 32 to 158 °F (0 to 70 °C) |
| Operating Temperature | 32°F to 158°F (0°C to 70°C) |
