Features
- Bandwidth of 25MHz with two channels for a wide range of signal analysis.
- Sampling rate of 250MS/s to capture fast-changing signals with high detail.
- Memory depth of 25kpts for storing and analyzing long waveform records.
- Vertical scale from 1mV/div to 20V/div to handle various signal amplitudes.
- 7-inch TFT LCD display provides a clear, detailed view of waveforms.
- USB interface cable
Technical Specifications
| Bandwidth | 25MHz |
| Channels | 2 |
| Sampling Rate | 250MS/s |
| Rise Time | <14ns |
| Memory Depth | 25kpts |
| Waveform Capture Rate | >2,000wfms/s |
| Vertical Scale (V/div) | 1mV/div-20V/div |
| Time Base Scale (s/div) | 10ns/div-50s/div |
| Storage Methods | Setup, waveform, bitmap |
| Frequency Counter | 6 bits |
| Trigger Types | Edge, pulse width, video, alternate |
| Level Range | Internal: ±8div from screen center; EXT: ±3V |
| Holdoff Range | 80ns to 1.5s |
| Edge Trigger Types | Rise, fall, rise & fall |
| Interfaces | Pass/Fail (UTD2025CL), USB-OTG |
| Power | 100V to 240V ACrms, 50Hz/60Hz |
| Display | 7-inch TFT LCD, WVGA (400×240) |
| Product Color | White and grey |
| Product Size | 12.05in x 5.79in x 4.80in (306mm x 147mm x 122mm) |
| Product Net Weight | 4.85 lb (2.2kg) |
