Technical Specification
| Wavelength | 1270 nm-TX or 1330 nm-RX |
| Transmitter Type | DFB |
| TX Power | -4.3 dBm to 4.5 dBm |
| Max Power Budget | 13 dB |
| Power Consumption | ≤5 W |
| DDM/DOM | Supported |
| Max Data Rate | 103.1 Gbps |
| Max Cable Distance | 12.42 mi (20 km) |
| Receiver Reflectance | -14.5 dBm |
| Receiver Overload | 4.5 dBm |
| Extinction Ratio | >4 dB |
| Commercial Temperature Range | 32 °F to 158 °F (0 °C to 70 °C) |
