Features
- Supports 9.95Gb/s to 10.5Gb/s bit rates
- RoHS-6 Compliant (lead-free)
- Hot-pluggable XFP footprint
- Maximum link length of 49.71 mi
- Cooled CWDM EML
- APD Receiver
- Full Duplex LC connector
- No Reference Clock required
- Built-in digital diagnostic functions
- Standard bail release mechanism
Technical Specifications
| Form Factor | XFP |
| Data Rate | 10 Gbps |
| Fiber Type | SMF |
| Connector Type | Dual LC |
| Wavelength | 1470 nm to 1570 nm |
| Distance | 49.71 mi (80 km) |
| Tx Power | 0 dB to 5.5 dB |
| Rx Sensitivity | ≤-23 dB |
| Use | FTTX |
| Network | Wireless LAN, Bluetooth, Wired LAN, Wi-Fi |
| Power dissipation | <2.0 W |
| Commercial temperature range | 23 ℉ to 167 ℉ (-5 °C to 75 °C) |
