Overview
Emissions And Stack copper SFP+ BIDI transceiver is designed for bi-directional 10 G serial optical data communications such as IEEE 802.3 ae 10 GBASE-BX by using 1330 nm (1270 nm) transmitter and 1270 (1330) nm receiver. The transceiver consists of two sections: The transmitter section uses a multiple quantum well 1330 nm (1270) nm DFB laser and is a class 1 laser compliant according to International Safety Standard IEC 60825. The receiver section uses an integrated 1270 nm (1330 nm) detector preamplifier (IDP) mounted in an optical header and a limiting post-amplifier IC.
Features
- Operating data rate up to 10.3 Gbps
- Up 1270 nm DFB Transmitter, 1330 nm Receiver (AXB 23-192-20-D)
- Down 1330 nm DFB Transmitter, 1270 nm Receiver (AXB 32-192-20-D)
- Distance up to 12.49 mi over SMF
- Single 3.3 V Power supply and TTL Logic Interface
- LC Connector Interface, Hot Pluggable
- Compliant with SFP+ MSA Specification SFF-8431
- Compliant with IEEE 802.3 ae 10 GBASE-LR
- Compliant with IEEE 802.3 ae 10 GBASE-LW
- Compliant with SFF-8472
Technical Specifications
| Data rate | 10 Gbps |
| Distance | 1.86 mi (3 KM), 12.49 mi (20 KM) |
| Wavelength | 1310 nm, 1550 nm |
| Application | FTTH FTTB FTTC |
| Fiber Type | SMF |
| Connector | LC |
| Power supply | 3.3 V |
| Use | FTTH |
| Operating Case Temperature Standard | 32 ℉ to 158 ℉ (0 ℃ to 70 ℃) |
