Features
- 4 CWDM lanes MUX or DEMUX design
- Up to 11.2 Gbps per channel bandwidth
- Aggregate bandwidth of >40 Gbps
- Duplex LC connector
- Compliant with 40 G Ethernet IEEE 802.3 ba and 40 GBASE-LR4 Standard
- QSFP MSA compliant
- Up to 6.21 mi (10 km) or 12.42 mi (20km) transmission
- Compliant with QDR or DDR InfiniBand data rates
- Single +3.3 V power supply operating
- Temperature range 32 °F to 158 °F (0 °C to 70 °C)
Technical Specifications
| Data Rate | 40 Gb/s |
| Rate of Channel Bandwidth | 11.2 Gbps |
| Wavelength | 1271 nm to 1291 nm or 1311 nm to 1331 nm |
| Max Distance | 12.42 mi (20 km) |
| Power Supply | 3.3 V |
| Operating Temperature | 32 °F to 158 °F (0 °C to 70 °C) |
