Features
- Precise Positioning and Measurement
- Waterproof and Durable
- Versatile Mounting Options
- Wide Range of Output Options
Technical Specifications
| Housing Material | Plastic |
| Amounting Way | Flush or Non-Flush |
| Output | NPN or PNP NO or NC |
| Operating Voltage | DC 10 V to 30 V |
| No Load Current | < 10 mA |
| Max Load Current | 150 mA |
| Leakage Current | < 0.01 mA |
| Voltage Drop | < 1.5 V |
| Ripple | < 10% |
| Switching Frequency | 100 Hz |
| Response Time | < 1.5 ms |
| Switching Hysteresis | < 15% (Sr) |
| Repeat Accuracy | < 5.0% (Sr) |
| Protection Category | IP67 |
| Temperature Drift | < 10% (Sr) |
| Overload Protection | 180 mA |
| Reverse Polarity Protection | Yes |
| Short Circuit Protection | Yes |
| Standard Cable Length | 6.56 ft (2 m) |
| Sensing Distance | 0.08 in or 0.12 in or 0.16 in or 0.24 in (2 mm or 3 mm or 4 mm or 6 mm) |
| Operating Temperature | -13 °F to 158 °F (-25 ℃ to 70 ℃) |
