Features
- Fast & efficient gas detection function
- Rich human-machine interface
- Large data storage & multi-storage
- Powerful and convenient humanized function
- Multiple optimal function meets personalized needs
- Up to 24 gases are monitored
- Has Wi-fi USB network connection
Technical Specifications
| Gases to be Detected | Arbitrary combination of 1 to 6 gases (expandable to 18+ types) including toxic gases, oxygen, carbon dioxide, inflammable and explosive gases, TVOC, etc. |
| Detection Range | F2: 0 to 50 ppm HF: 0 to 50 ppm SO2: 0 to 10000 ppm NO: 0 to 5000 ppm NO2: 0 to 100 ppm NOX: 0 to 1000 ppm |
| Resolution | 1 ppm |
| Detection Principle | PID photoionization (customizable depending on gas type, range, environment, and user demand) |
| Allowable Error | ≤ ±2% F.S (higher precision levels customizable) |
| Sample Gas Temperature | -40 °F to 158 °F (-40 °C to 70 °C), with optional high-temperature sampling & cooling filter handle for detecting smoke gas up to 2372 °F (1300 °C) |
| Power Supply | 3.6 VDC, 10000 mAh high-capacity rechargeable polymer battery |
| Display Mode | 3.5 in high-definition color screen |
| Detection Mode | Built-in pump suction type measurement, flow rate 800 ml or min |
| Battery Span | 12 hours |
| Alarm Mode | Sound alarm, light alarm, vibration alarm, switch-off alarm |
| Protection Level | IP66 |
| Explosion-Proof Type | Intrinsically safe |
| Explosion-Proof Mark | Exia II CT6 |
| Temperature | -40 °F to 158 °F (-40 °C to 70 °C) |
| Humidity | ≤ 10% to 95% RH |
| Dimensions | 9.05 in × 8.26 in × 4.72 in (23 cm × 21 cm × 12 cm) |
| Weight | 5.5 lb (2.5 kg) |
