Features
- Small and light, easy to carry
- Blade life more than 48000 times
- Support cleaved length 5in 20 mm
- High quality materials, stable performance
- High precision, specially designed for splicing work Apply to 250 p.m/ 900 p.m fibers, tail optical
- Fiber with 2-3mm in diameter, FTTH butterfly leather cable
Technical Specifications
| Specification | Detail |
| Fiber Cladding Diameter | 125µm |
| Fiber Coating Diameter | 160µm ~ 3000µm |
| Fiber Type | Single core fiber |
| Cleaved Length | 5 mm to 20mm |
| Cleaved Angle | ≤ 0.7° |
| Blade Life | 48000 times |
| Operation Mode | Semi-automatic |
| Dimension | 58mm (W) x 55 mm (D) x 54mm (H) |
| Weight | 210 g |
