Overview
Emissions and Stack medical liquid color checker colorimeter is designed for simple operation with durable function and permit speedy accurate measurement in routine analysis. This consists of the lamp, hear-absorption filter, lens and diaphragm. The light traversing in this system falls on our rent generating photocell which actuates a direct reading micro ammeter.
Features
- High Stability and Reproducibility for reliable results
- Economic operation with low reagent consumption
- Utilizes a silicon photocell for accurate measurements
- ±5 nm Wavelength reproducibility for precise analysis
- Equipped with a 6 V, 0.5 A tungsten lamp
Technical Specifications
| Power | 110 V or 220 V AC 10 W |
| Economy | Consumes only 1.5 ml of reagent |
| Economy | Silicon photocell |
| Wavelength Range | 420 nm to 660 nm |
| Photoelectric Range | T% 0% to 100%, ABS log TO 2 |
| Photoelectric Accuracy | 2 T |
| Light Source | 6 V 0.5 A tungsten lamp |
| Dimension | 11.02 in × 8.66 in × 4.80 in (280 mm x220 mm x122 mm), 14.17 in × 14.17 in × 7.87 in (360 mm x 360 mm x 200 mm) |
| Weight | 6.61 lb (3 kg) (body only) |
