Features
- Up to 11.3 Gbps data links
- +3.3 V single power supply
- Power dissipation <1.5 W
- Support hot swap
- 10 Gbps
Technical Specifications
| Wavelength | 1270 nm to 1330 nm |
| Data Rate | 11.3 Gbps |
| Power Dissipation | < 1.5 W |
| Supply Voltage | 3.15 V to 3.45 V |
| Bias Current | 10 Ma to 80 Ma |
| Tx Power | -5 dBm to 5 dBm |
| Rx power | -16 dBm to 0 dBm |
| Power Supply | 3.3 V |
| Transmission Distance | 6.21 mi (10 km) |
| Operating Temperature | 32 °F to 158 °F (0 °C to 70 °C) |
