| Transmitter Pulse |
Square Wave Pulsar |
| Transmitter Pulse Voltage |
25 V to 400 V, continuously |
| Test Modes |
Pulse echo and dual transmission |
| Damping |
400 Ohm to 80 Ohm |
| Frequency |
0.5 MHz to 20 MHz Broadband / narrowband optional |
| Gain |
0.0 dB to 120.0 dB Steps as 0.1 dB, 1.0 dB, 2.0 dB, 6.0 dB |
| Material Velocity |
1000 m/s to 15000 m/s continuously adjustable. 30 common material velocities selectable |
| Rectification |
Positive half wave, negative half wave, full wave, RF |
| Alarm |
Real time alarm signal indicated by horn or LED indicator |
| Display |
5.7 in high brightness TFT colour LCD |
| Pulse Shift |
-20 μs to 3400 μs |
| Probe Zero Offset |
0 μs to 999.9 μs |
| Pulse Repetition Frequency |
25 Hz to 1000 Hz, auto and manual adjustment modes |
| Vertical Linearity Accuracy |
≤2% |
| Horizontal Linearity Accuracy |
≤0.1% |
| Surplus Sensitivity |
≥65 dB |
| Resolutions |
≥45 dB |
| Dynamic Range |
≥32 dB |
| Reject (Suppression) |
0% to 99% |
| Electric Noise Level |
<10% |
| Interface |
C 6 transducer connections, USB HOST, LAN, RF OUT, Two-dimensional encoder interface |
| Power Supply |
Large capacity Li Battery, no memory effect; Battery Operating time: More than 6 hrs |
| Relative HumIDity |
20% RH to 95% RH |
| Environmental Temperature |
4 °F to 122 °F (-20 ℃ to 50 ℃) |
| Size |
18.89 in x 15.35 in x 6.29 in (48 cm x 39 cm x 16 cm) |
| Weight |
2.20 Ib (1 Kg) (with battery) |
