Technical Specifications
| Frequency | 0.2 MHz to 20 MHz |
| Sound Velocity | 100 m/s to 20000 m/s |
| Pulse Shift | -5 μs to 3400 μs in steel (dependent on range) |
| Zero Point Probe | 0 μs to 100 μs |
| Vertical Linear Error | ≤3% |
| Horizontal Linear Error | ≤0.1% |
| Dynamic Range | ≥40 dB |
| Communications | Connect with computer through RS 232 or USB |
| Average Electric | ≤20% |
| Gate Alarm | Wave to entering gate, wave to losing gate sound alarm, width, height, location, continuous tuning |
| Time Of Working | 7 hrs |
| Power Supply | 220 V AC, 110 V DC |
| Temperature | 14 °F to 140 °F (-10 °C to 60 °C) |
| Sensitivity Surplus | ≥60 dB, 7.87 in (200 mm), (depth, 2 flat bottomed hole) |
| Detection Range | 0 in to 393.7 in (0 mm to 10000 mm) |
| Colour TFT LCD | 5.25 in x 3.87 in (133 mm x 98 mm), 640 pixels x 480 pixels VGA colour |
| Appearance Size | 11.89 in x 9.88 in x 2.08 in (302 mm x 251 mm x 51 mm) |
| Net Weight | 5.51 lb (2.5 kg) with Li Ion Battery4.85 lb (2.2 kg) without battery |
