Features
- Compliant with 40G Ethernet IEEE802.3 ba and 40GBASE-ER4 Standard
- QSFP + MSA compliant
- Compliant with QDR or DDR InfiniBand data rates
- Up to 10.7 Gb/s data rate per wavelength
- 4 CWDM lanes MUX or DEMUX design
- Up to 24.85 mi (40 km) transmission on single-mode fiber (SMF)
- Operating case temperature: 32 °F to 158 °F (0 °C to 70 °C)
- Maximum power consumption 3.5 W
- LC duplex connector
- RoHS compliant
Technical Specifications
| Network | Wireless Lan, Bluetooth, Wired LAN, ONVIF, SDK, TCP, Ip, POE, GPRS, WIFI, 4 g, GSM, 3 G, Wiegand |
| Data Rate | 40 Gb/s |
| Form Factor | QSFP+ |
| Wavelength | 1264 nm to 1337 nm |
| Connector | LC Duplex |
| TX Power | -3.7 dBm to 4.5 dBm each lane |
| Receiver Sensitivity | -18 dBm |
| Max Cable Distance | 18.64 mi (30 km) |
| Use | FTTH |
| Temperature Range | 32 °F to 158 °F (0 °C to 70 °C) |
