| Average Splice Loss |
0.02 dB (SM), 0.01 dB (MM), 0.04 dB (NZDS), 0.04 dB (EDF) |
| Return Loss |
≥60 dB |
| Tension Test |
2.0 N (200 gf) (Standard) |
| Typical Splicing Time |
8 s |
| Typical Heating Time |
25 s |
| Splicing Program |
50 groups |
| Protection Sleeve Length |
0.7 in, 1.5 in, 2.3 in (20 mm, 40 mm, 60 mm) |
| Environmental Conditions |
14 °F to 122 °F (-10 °C to 50 °C) (operation temperature), 0% to 95% RH (humidity), 3.10 mi (5000 m) (altitude) |
| Power Supply |
AC adaptor: 100 V to 240 V input voltage, 50 HZ or 60 Hz; 12V, 5A output voltage (DC) Battery: 12 V voltage 8 AH |
| Fiber Image Magnification |
Simultaneous X and Y views with 400 times magnification |
| Storage Of Splice Result |
6,000 groups of splice results |
| Splicing Model |
Auto & Manual & Full Auto |
| Optical Fiber Fixture |
3-in-1 cutting fixture |
| Dimensions |
5.11 in x 5.3 in x 5.11 in (130 mm x 135 mm x 130 mm) |
| Weight |
3.8 lb + 0.83 lb (1.74 kg + 0.38 kg) (battery weight) = 4.6 lb (2.12 kg); Package G.W.: 13.2 lb (6.03 kg) |
