Features
- 10 Gb/s serial optical interface compliant
- Electrical interface compliant to SFF – 8431 specifications
- 1270 nm or 1330 nm DFB transmitter
- PIN photo – detector
- 2 wire interface for management specifications compliant
- metal housing for superior EMI performance
- Low power consumption
- Advanced firmware allows customer system encryption information to be stored in transceiver
- Cost effective SFP + solution
- Enables higher port densities and greater bandwidth
- Temperature Range 32 °F to 158 °F (0 °C to +70 °C)
Technical Specifications
| Type | Fiber Optic Transceivers |
| Number of Fiber | 2 |
| Use | FTTH |
| Connector type | LC |
| Wavelength | 1550 nm |
| Max Data Rate | 10.31 Gbps |
| Distance | 24.52 mi (40 km) |
| DOM or DDM Support | Yes |
| Power supply | 3.3 V |
| Operating temperature | 32 °F to 158 °F (0 °C to +70 °C) Standard |
