Technical Specifications
| Network | GPRS |
| Wavelength | 1550 nm ± 20 nm, 1310nm, 1550 nm ± 20 nm |
| Fiber Type | Single mode fiber |
| Event Blind Zone | 8.20 ft (2.5 m) |
| ATT Blind Zone | 26.24 ft (8 m) |
| Measuring Range | 0.31 mi, 0.62 mi, 1.24 mi, 2.49 mi, 4.97 mi, 9.94 mi, 19.88 mi, 39.77 mi, 62.14 mi (500 m, 1 km, 2 km, 4 km, 8 km, 16 km, 32 km, 64 km, 100 km) |
| Pulse Width | 3 ns to 20 us |
| Sampling Resolution | 0.164 ft to 26.24 ft (0.05 m to 8 m) |
| Data Storage | 8 G |
| Laser Safety Grade | Class 2 |
| Frequency Identification | CW, 270 Hz, 330 Hz, 1kHz, 2 kHz |
| Use | Optical fiber test |
