| Applicable Optical Fiber Types |
SM (Single mode), MM(Multi-mode), DS (Dispersion shift), NZDS (Non zero dispersion shift) |
| Applicable Optical Fiber Core Number |
Single core |
| Applicable Optical Fiber Diameter |
Cladding diameter:125 μm, Coating diameter:250 to 900 μm |
| Average Fusion Splice Loss |
0.03 dB (SM), 0.02 dB (MM), 0.06 dB (DS), 0.06 dB (NZDS) |
| Alignment |
Both core alignment and c lading alignment |
| Echo Loss |
Better than 60 dB |
| Fusion splice Duration Time |
7sec (typical parameter) |
| Loss Estimation of Fusion Splice |
Exist |
| Tension Test |
2N |
| Monitor |
4.3 inches colorized LCD, English and Chinese caption. |
| Optical Fiber Magnification Times |
X/Y:115 times, X or Y:230 times |
| Power Supply |
11.1 V Lithium battery, 13.5V/5A power adapter, 12 V power source available on the car |
| Battery |
Typically work 180 times (Fusion splicing or Heating), Single battery charge 3 Hour, can be recycled 500 times |
| Splice Results Storage |
5000 groups of the latest records |
| Data Interface |
USB 2.0 |
| Operating Environment |
Elevation:0 to 4000 m, Relative humidity:0 to 95%, Temperature: 14 °F to 131 °F (-10 °C to 55 °C) Maximum wind speed:12 m/s |
| Storage Environment |
Relative humidity:0 to 95%, Temperature: -40 °F to 176 °F (-40 °C to 80 °C) (Except Battery), Temperature: 14 °F to 86 °F (-10 °C to 30 °C) (Battery) |
| Weigh |
3.57 lb Exclude battery (1.6 KG Exclude battery), 3.96 lb Include battery (1.8 KG Include battery) |
| Size |
5.90 in x 5.11 in x 5.09 in (150 mm x 130 mm x 128 mm) |
