Features
- Easy to use
- Portable, light, rugged
- More accurate testing results
- Automatic pulse width control
- Small and light, easy to carry
Technical Specifications
| Operating Wavelength | 1550 nm |
| Display | 2.6 in (6.60 cm) |
| Dynamic Range | 22 dB |
| Pulse Width | 10 ns to 10 µs |
| Reflection Even Dead Zone | 8.62 ft (3 m) |
| Attenuation Dead Zone | 32.80 ft (10 m) |
| Power of VFL | 1 mW |
| Loss Resolution | 0.001 dB |
| Minimum Distance Resolution | 3.93 in (0.1 m) |
| Humidity | 0% to 85% |
| Working Temperature | 23 ℉ to 104 ℉ ( -5 ℃ to 40 ℃) |
| Storage Temperature | 14 ℉ to 140 ℉ ( -10 ℃ to 60 ℃) |
| Weight | 0.66 lb (300 g) |
