Technical Specifications
| Dynamic range | 32 dB or 30 dB, 1310 nm or 1550 nm |
| Event Dead Zone | < 6.56 ft (2 m) |
| Distance uncertainty | ±(29.52 in (0.75m) + sample space + measurement distance×0.003 %) |
| Sampling resolution | 1.96 in, 3.94 in, 7.87 in, 19.68 in, 3.2 ft, 6.56 ft,13.1 ft,26.2 ft, 52.4 ft(0.05 m ,0.1 m,0.2 m,0.5 m,1 m,2 m,4 m,8 m,16 m) |
| Distance range | 0.24 mi, 0.49 mi, 0.99 mi, 1.98 mi, 3.97 mi, 9.94 mi, 19.8 mi, 39.7 mi, 79.5 mi, 159.07 mi, 318.1 mi (0.4 km,0.8 km,1.6 km,3.2 km,6.4 km,16 km,32 km,64 km,128 km,256 km,512 km) ( (SMF); 0.4 nm,0.8 nm,1.6 nm,3.2 nm,6.4 nm,16 nm,32 nm (MMF of 850 nm) |
| Pulse width | 5 ns,10 ns,30 ns,80 ns,160 ns,320 ns,640 ns,1280 ns,5120 ns,10240 ns ,20480 ns 5 nm,10 nm,30 nm,80 nm,160 nm,320 nm,640 nm,1280 nm (MMF of 850 nm) |
| Loss threshold | 0.01 dB |
| Sampling points | Up to 128 k |
| Linearity | 0.05 dB or dB |
| Loss resolution | 0.001 dB |
| Memory capacity | ≥800 traces (build in) ≥65500 traces (1GB SD storage) |
| Group refractive index setting | 1.00000 to 2.00000 (0.00001steps) |
| Distance unit | km, m, kft, ft |
| Display | 640 pixels × 480 pixels, 6.5 in (16.5 cm) TFT LCD (touch screen) |
| Interface | USB, SD |
| Optical connector | FC or SC or LC (universal connector) |
| Optical Power Meter | Wavelength range: 1270 nm to 1700 nm Measurement exfiber range: -60 dBm to +3 dBm Measurement accuracy: 5% ( -10 dBm, CW) |
| Power supply | AC adapter 100 V to 240 V, 50 Hz or 60 Hz, 1.5 A DC:19 V ±2 V (2 A) Built in Lithium battery: 4400 mAh, operating time ≥8 hrs |
