Features
- Built-in OPM or VFL, OLS or FIP
- 1:16 splitters
- 28 ft (1 m) events dead zone
- Link map and pass
- Dual wavelengths testing
- Brand new UI design
- Bets-in-class trace analysis
Technical Specifications
| Event Blind Zone | 3.28 ft (1 m) |
| ATT Blind Zone | 11.48 ft (3.5 m) |
| Pulse Width | 5 ns to 2000 ns |
| Loss Accuracy | ±0.03 dB/dB |
| Sampling Accuracy | 1.57 in (0.04 m) |
| Reflection Accuracy | ±2 dB |
| Data Storage | Internal: ≥1000 |
| Work Wavelength | 650 nm ± 20 nm |
| Uncertainty | ±5% |
| Modulation Frequency | 270 Hz, 1kHz or 2kHz |
| Display | 3.5 in (8.89 cm) screen |
| Power Supply | 3000 mAh |
| Battery Life | Standby > 20 hrs, Measuring time > 12 hrs |
| Relative Humidity | 0% to 95% |
| Operating Temperature | 14 ℉ to 122 ℉ ( -10 ℃ to 50 ℃) |
| Storage Temperature | -40 ℉ to 158 ℉ ( -40 ℃ to 70 ℃) |
| Dimension | 8.58 in x 4.64 in x 2.16 in (218 mm x 118 mm x 55 mm) |
| Weight | 1.65 lb (≤750 g) |
