| Size / Proportion |
13.3 in, 16:9 |
| Resolution |
1920 × 1080 |
| Brightness |
450 cd/m² (optional 1000 cd/m²) |
| Contrast Ratio |
1000:1 |
| Display Color |
16.7 million |
| Response Time |
2 ms |
| Viewing Angle |
85° / 85° / 85° / 85° |
| Pixel Pitch |
0.0060 in × 0.0060 in (0.15285 mm × 0.15285 mm) |
| Pixel Density |
166 PPI |
| Type |
Projected multi-point capacitive (10 points) |
| Hardness |
6H |
| Positioning Accuracy |
< 0.08 in (< 2 mm) |
| Click Life |
≥ 50 million times |
| Touch Media |
AG anti-glare capacitive screen |
| Right-Click Function |
Hold for more than 3 seconds |
| CPU |
RL3568 quad-core Cortex-A55, up to 2.0 GHz |
| Operating System |
Android 11.0 or Debian 10 |
| Memory |
Optional 2 GB or 4 GB DDR4 |
| Storage |
Onboard eMMC (16 GB or 32 GB optional) |
| Wireless Connectivity |
Wi-Fi, Bluetooth |
| Speaker |
Built-in speaker |
| Power Input |
DC 12 V (customizable wide voltage 12 V to 36 V) |
| Interfaces |
CAN, COM, E2, Wi-Fi, Audio, USB 2.0, USB 3.0, SIM, TF, HDMI, LAN, DC12V |
| Vibration Resistance |
30 Hz, X/Y/Z axis, 60 minutes each |
| ESD Protection |
Class 3, ±6 kV contact discharge, ±8 kV air discharge |
| Panel Level |
IKG |
| Operating Temperature & Humidity |
14 °F to 140 °F (-10 °C to +60 °C), 0–80% RH (no condensation) |
| Storage Temperature & Humidity |
5 °F to 149 °F (-15 °C to +65 °C), 0–90% RH (no condensation) |
