Features
- 6 motors accurate real core to core alignment
- 5 inch high resolution color touch screen
- 6 seconds splicing and 18 seconds heating
- Automatic and real time ARC calibration Industrial quad core CPU with 30% power saving
- Anti shock, anti vibration, dustproof and waterproof
- Apply to 250 μm or 0.9 mm or 2.0 mm or 3.0mm fibers and SOC
Technical Specifications
| Alignment Method | 6 motors core to core |
| Cladding | 80 um to 150 um |
| Return Loss | > 60 dB |
| Coating | 160 um to 3000 um |
| Splicing Program | 40 groups |
| Operating Mode | Manual or auto |
| Heating Time | 18 s |
| Storage | 4000 groups |
| Tension Test | 1.8 N to 2.25 N |
| Battery | 5200 mAh |
| Power Supply | Input AC 100 V to 240, output : DV 11 V to 13.5 V |
| Electrode Life | More than 4000 Arc |
| Altitude | 0 m to 5000 m |
| Humidity | 0 % to 95 % |
| Temperature | 14 ℉ to 122 ℉ (-10 ℃ to 50 ℃) |
| Size | 6.14 in x 5.55 in x 6.14 in (15.6 cm x 14.1 cm x 15.6 cm) |
| Weight | 5.4 lbs (2.45 kg) |
