Features
- Supporting DWDM transmission, wavelength conversion.
- Supporting up to 40 KM without relay.
- Supporting multiple client-side service access: QSFP28 (100GBase-SR4/CWDM4/LR4/PSM4).
- Supporting CDR function, which can optimize output, DDM signal monitoring and ALS (Automatic Laser Shutdown) function.
- Supporting SNMP-based unified network management platform, network management mode CLI, WEB, NetRiver (graphical interface).
- Supporting software to close the port.
- Supporting line-side: CFP or CFP2, coherent and tunable.
Technical Specifications
| Wavelength Range | DWDM: C-Band (100 GHZ or 50 GHZ). Tunable. |
| Service Access Types | 100 GE, OTU4. |
| Dispersion Tolerance | ±40000 ps, nm@100 G ±10000 ps, nm@200 G |
| OSNR Tolerance | <12.5 dB@100 G <21 dB@200 G |
| Network Management Functions | CDR function (DDM real-time monitoring), ALS (Automatic Laser Shutdown) function, service access one-way or bidirectional setting. |
| Network Management Mode | CLI, NetRiver, WEB. |
| Working Temperature | 14 °F to 158 °F (-10 ℃ to70 ℃) |
| Storage Temperature | -40 °F to 185 °F (-40 ℃ to 85 ℃) |
| Relative Humidity | 5 % to 95 % no condensation |
| Product Dimension | 177 mm (W) x 40 mm (H) x 225 mm (D) |
| Safety And EMC | Compliance with FCC or UL or CE or TUV or CSA standards. |
| Power Consumption | <21 W |
