Features
- Main control chip A133
- CPU 64-bit 4 core A53
- Maximum main frequency 1.6 GHz
- Memory 1 G or 2 G or 4 G LPDDR4
- Storage 16 G or 32 GB or 64 GB EMMC
- Graphics processor IMG Power VR GE8300
- Supports OpenGL ES3.2, Vulkan 1.1, Open CL 1.2
- Video processor H.265 Video Decoder 4 K at 30 fps,
- 264 video decoder 4 K at 30 fps, VP9 Video decoder 720 p at 30 fps
- 264 Video encoder 1080 p at 60 fps, MJPEG or JPEG Baseline
- encoder 4 K at 15 fps
- Decoding 1080 p at 60 Hz
- 4G EC20 module (software support)
- 2 MIPI camera interface, complete power supply
- maximum 13 M pixel support
- Currently supports LCD 5 in (12.7 cm) (720 x 1280)
- 7 in (17.7 cm) (1024 x 600), 10.1 in (25.6 cm) (1280 x 800)
- other sizes can be customized
- USB 1 channel high-speed USB HOST
- Two MIC ports
- One headset output + MIC
- All the way double channel LINEOUT
- Route 1 leads out the SDIO port
- Power supply 5 V voltage input, 3.7 V battery input
- Provide source code (LINUX without hard decoding)
- reference design schematic and PCB
- diagram (ORCAD, PADS format)
- Provide paid software technical support
- hardware customization services, not free
- System Android 10.0, kernel 4.9 Ubuntu 18.04 (XFCE or Core) + QT5
Technical Specification
| Memory Capacity | 8 GB |
| Display resolution | 1920 x 1080 |
| Operating System | Linux + android 10.0 |
| Network | Wi-Fi, 4 G, 3 G |
| Feature | Hard |
| Private Mold | Yes |
| Processor Type | Quad Core |
| Processor Main Frequency | 1.6 |
| Touch Screen Type | Capacitive Screen |
| RAM | 2 G or 1 G or 4 G |
| Operating temperature | 14 ℉ to 158 ℉ (-10 °C to 70 °C) |
| Storage temperature | -40 ℉ to 257 ℉ (-40 °C to 125 °C) |
| Power supply | 5 V voltage input, 3.7 V battery input |
| Main control chip | A133 |
| CPU | 64-bit 4-core A53 |
| Maximum main frequency | 1.6 GHz |
| Memory | 1 G or 2 G or 4 G LPDDR4 |
| Storage | 16 G or 32 GB or 64 GB EMMC |
| Graphics processor | IMG Power VR GE8300, Supports OpenGL ES3.2, Vulkan 1.1, Open CL 1.2 |
| Video processor | H.265 Video Decoder 4 K at 30 fps, H.264 video decoder 4 K at 30 fps, VP9 Video decoder 720p at 30 fps, H.264 Video encoder 1080p at 60 fps, MJPEG or JPEG Baseline encoder 4 K at 15 fps |
| Decoding | 1080 p at 60 Hz |
| Screen Size | 10.1 in (25.6 cm) |
| Single package size | 9.2 in x 7.6 in x 2.5 in (23.5 cm x 19.5 cm x 6.5 cm) |
| Weight | 2.6 lb (1.2 kg) |
