| Measurement Frequency |
100 Hz to 100 kHz |
| Basic measurement accuracy |
0.15 % |
| Equivalent circuit |
Series, parallel |
| Mathematical functions |
Percentage deviation |
| Range way |
Automatic, hold, manual selection |
| Trigger mode |
Automatic, manual, external, bus |
| Measure (>= 1 KHz) |
Fast 30 times per second, middle speed 10 times per second, low speed 3 times per second |
| Average time |
1 to 255 |
| Delay time |
0 sec to 6 sec, step by 1 ms |
| Calibrating |
Open or short circuit or quick reset |
| Display mode |
Direct reading, delta %, V or I |
| Displayer |
5-digit display of main and minor parameters, 4.3 in (10.9 cm) true color LCD displayer |
| Output impedance |
30 Ω and 100 Ω |
| Display of |Z|, R, X, ESR |
0.1 mΩ to 99.999 MΩ |
| Display of C |
0.01 pF to 9.9999 F |
| Display of L |
0.01 µH to 99999 H |
| Display of D |
0.0001 to 9.9999 |
| Display of Q |
0.0001 to 9999.9 |
| Degree |
-179.999 degrees to 179.999 degrees |
| Radians |
-3.1416 to 3.1416 |
| Delta % |
-999.99 % to 999.99 % |
| Comparator function |
5 grade of sorting function |
| Storage |
More than 100 sets of instrument settings for storage or call, U disk extension of more than 500 sets |
| Interface |
RS232C, HANDLER, USB and HOST standard |
| Dimensions |
10.4 in x 3.9 in x 13.3 in (265 mm x 100 mm x 340 mm) |
| Weight |
7.7 lb (3.5 kg) |
