Overview
Emissions and Stack cleanroom dust particle counter is a crucial tool for filter detection. Specifically designed for use with particle counters, this diluter is employed to measure the upstream concentration of filters, preventing contamination by ensuring it doesn’t exceed the saturation concentration of the particle counter. Ideal for maintaining clean environments, it plays a vital role in accurately counting particles.
Features
- Connects to a 1 CFM particle counter and aerosol sampling tube
- Dilution options 10:1 or 100:1 for various aerosols
- Monitors pressure drop differentially
- Uses flow control and feedback for workflow adjustment
- Developed by a skilled team with patented technology
Technical Specifications
| Sampling | 28.3 L/min (Desviacion ≤±5%) |
| Aerosol | PAO 4, DOP, Ondina, Mineral Oil, Paraffin |
| Particle size range | 0.1 μm, 0.2 μm, 0.3 μm, 0.5 μm |
| Dilution ratio | 10 times, 50 times, 100 times |
| Inlet and outlet diameter | 0.433 in (11 mm) |
| Power | Not required (to use a suction counter or photometer) |
| Repeatability | Desviación estándar ≤ 10% |
| Material | SUS 316 L |
| Size | 13.110 in × 11.929 in × 5.966 in (333 mm x 303 mm x 151.5 mm) |
| Weight | 15.432 lb (7 kg) |
