Features
- Designed for non-lighting and non-fluorescent samples
- Useful for textiles, paper, leathers, painting materials
- Colour difference displayed in various metrics
- Colour space displayed in different models
- Statistical functions (Maximum, Minimum, Average, Standard Deviation)
- Colour difference tolerance for PASS or WARN or FAIL
- Stores 9 colour difference target colours
- User calibration for higher accuracy
- Auto memory (99 sets) & Read function
- Digital backlight display
- Auto power-off function
- USB and Bluetooth data output options.
Technical Specifications
| Display | Triple 4-digit LCD Display |
| Auto Power Off | Approx. 3 minutes |
| Data Memory Capacity | 99 sets (Direct reading from LCD display) |
| Illuminating or Viewing Geometry | 45° or 0° Illumination at 45°, measurement at 0° |
| Measuring Area | Colour Difference (L, a, b), (E x ab, C x ab, H x ab), (Y, x, y), (X, Y, Z), (Rs, Gs, Bs) or (WI, YI, Tw) to Colour Space (L, a, b), (L, C x ab, hab), (Y, x, y), (X, Y, Z), (Rs, Gs, Bs) or (WI, YI, Tw) |
| Target Colour Memory | 9 channels set by measurement or keypad |
| Measuring Range | 5 L to 100 L |
| Measurement Conditions | Observe CIE 2° Standard Observer |
| illuminate | White LED lamp |
| Repeatability | Standard deviation within E x ab 0.5 (Measurement conditions: Average of measurements of standard white plate) |
| Minimum Interval Between Measurements | 2 seconds |
| Power Source | 4 x 1.5 AAA (UM-4) Battery |
| Operating Temperature | 0 °C to 40 °C (32 °F to 104 °F) |
| Operating Humidity | < 85% RH |
| Storage Temperature and Humidity | -10 °C to 40 °C (14 °F to 104 °F) |
| Storage Humidity | < 70% RH |
| Dimensions | 140 mm × 73 mm × 35 mm (5.5 in × 2.9 in × 1.4 in) |
| Weight | 7.76 oz (220 g) |
