Features
- 4-digit LED display for speed and mode
- LF-LED-OS software system
- LED indicators for various working statuses
- Combined toggle switch and knob operation
- Basic functions: start/stop, forward/reverse, full speed
- Simple dispensing control for repetitive liquid transfers
- Streamlined plastic shell design
- Large torque output for multi-channel applications
- Double-layer isolation, three anti-paint circuit board
- Super anti-interference, wide voltage design
- External control with high/low-level start/stop
Technical Specifications
| Power Supply | AC 100 V to 240 V, 50 Hz or 60 Hz |
| Voltage | 240 V |
| Power | < 30 W |
| Speed Accuracy | < ± 0.5 % |
| Speed Resolution | 0.1 rpm to 100 rpm: 0.1 rpm; 100 rpm to 600 rpm: 1rpm |
| Rotation Range | 0.1 rpm to 150 rpm |
| FIow Range | 0.0001 ml/min to 720 ml/min |
| Working Environment | Ambient temperature 32 °F to 104 °F (0 °C to 40 °C), relative humidity < 80 % |
| Protection Level | IP31 |
| Dimensions | 10.28 in x 7.09 in x 7.76 in (261 mm x 180 mm x 197 mm) |
| Drive Weight | 9.92 lb (4.5 kg) |
