| Measure Parameters |
Refractive index(nD), Brix (%), Temperature (°C) |
| Measure range |
0% to 15%, 0% to 50%, 90% |
| Min Resolution Ratio |
Brix: 0.1% (Range for 15% , 0% to 50%) |
| Brix: 0.5% (Range for 90%) |
| Measurement Accuracy |
Brix: ± 0.1% |
| Brix: ± 0.3% (standard) |
| Operating current |
≤200 mA |
| Display menu |
Refractive index (nD), Brix (%), Temperature (°C) |
| Output |
4 mA to 20 mA, 4 mA to 20 mA + RS485 optional |
| Power |
12 V DC to 24 V DC |
| Wetted parts material |
Prism: sapphire, Prism stage: SS304, SS316L (can be customized) |
| Optical source |
LED (the wave length approximate to D line) |
| Max Pressure |
1 MPa |
| Protection grade |
IP67 |
| Process connection |
3” tri-clamp, other size supply free adaptor |
| High and low limit settings |
Buttons can be set |
| Environment Temperature |
32 °F to 104 °F (0 °C to 40 °C) |
| Measurement Temperature |
32 °F to 185 °F (0 °C to 85 °C) (Automatic Temperature Compensation) |
| Recorder output cable |
78.7 in (2 mm), 118.1 in (3 mm), 196.8 in (5 mm), 393.7 in (10 mm) optional |
| Instrument Size |
6.88 in x 4.72 in x 4.72 in (175 mm x 120 mm x 120 mm) |
