Overview
Emissions and Stack digital bluetooth color analyzer is a smart colorimeter which can provide color scan and color comparison for materials. The colorimeter complies with relevant international CIE standards. It adopts D or 8 illumination geometry and is equipped with a high-precision sensor that meets CIE. The colorimeter has good consistency and repeatability and need to be used with mobile app for accurate color measurement and quality control. Using this affordable colorimeter will boost your color quality when color requirements are too stringent to depend on visual evaluation alone. It is more accurate and reliable than other basic colorimeters.
Technical Specifications
| Illumination geometry | D or 8, Specular Component Include (SCI) |
| Illumination light source | Full spectrum LED light source |
| Measuring aperture | 0.31 in (8 mm) |
| Measurement conditions | Light source D65, field of view 10° |
| Measuring time | about 1 sec |
| Color spaces | CIE Lab, Luv, LCh, Yxy, CMYK, RGB, Hex |
| Color difference formulas | ΔE x ab, ΔE x uv, ΔE x 94, ΔE x cmc (2, 1), ΔE x cmc (1, 1), ΔE x 00 |
| Repeatability | Standard deviation ΔE x ab ≤ 0.03 (Measurement condition the average value of 30 measurements on the white tile at an interval of 3 sec after calibration) |
| Power supply | Rechargeable lithium battery 3.7 V at 700 mAh, can continuously measure 10,000 times under full charge |
| Data transmission | Bluetooth |
| Display | 0.96 in (2.4 cm) OLED |
| Operating temperature | 32 ℉ to 113 ℉ (0 ℃ to 45 ℃) |
| Operating humidity | 0% to 85% RH (no condensation) |
| Storage temperature | -13 ℉ to 131 ℉ (-25 ℃ to 55 ℃) |
| Storage humidity | 0% to 85% RH (no condensation) |
| Dimension | 2.2 in x 2.2 in x 3.5 in (57 mm × 57 mm × 89.4 mm) |
| Weight | about 4.44 oz (126 g) |
