Features
- Built-in white plate parameters
- Double locating, illuminating locating and precise cross locating
- Switchable double measurement end face
- New integrating sphere optical path design
- 1 in (4 mm) measuring aperture
- Equipped with rechargeable high-capacity li-ion battery
- Having got SCM metrological certification and CE certification
- Hand-head structure
- Exquisite appearance
- Spending huge sums on high-end mold
- High-cost performance
Technical Specifications
| Illuminating or viewing geometry | 8 per d |
| Measuring aperture | 0.1 in (4 mm) |
| Detector | Silicon photoelectric diode |
| Locating | Illuminating locating or cross locating |
| Measurement end face | Large stable end-face and small concave-convex end-face |
| Color space | CIEL x a x b x C x h x CIEL x a x b x CIEXYZ |
| Color difference formula | E x ab L x a x b x E x C x h x |
| Light source | D65 |
| Light source device | LED blue light excitation |
| Errors between each equipment | ≤0.80 e x ab |
| Storage | 100 pieces standards 20000 pieces samples |
| Repeatability | Standard deviation within E x ab 0.08 Average of 30 measurements of standard white plate |
| Language | English or Chinese |
| Power source | Rechargeable lithium-ion battery 3.7 V at 3200 mah |
| Lamp life | 5 years, more than 1.6 million measurements |
| Charging time | 8 hours 100% electricity |
| Weight | 15.87 oz (450 g) |
| Dimension | 8.07 in x 2.63 in x 3.14 in (205 mm × 67 mm × 80 mm) |
