Technical Specifications
| Bandwidth | 50 MHz |
| Input Impedance | 1 M? 25 pF |
| Colour | Black |
| DC accuracy | ? 3% |
| Vertical Resolution | 8 Bit |
| Channel | 2 Ch |
| Max. Sample rate | 150 MS/s |
| Coupling | AC or DC or GND |
| Gain range | 10 mV to 5 V, 9 Steps |
| Time Base range | 4 ns to 1 h, 38 Steps |
| Input protection | Diode clamping |
| X-Y | Yes |
| Auto set | Yes (30 Hz to 50 MHz) |
| EXT. input | Yes |
| Trigger Mode | Auto, Normal and Single |
| Trigger Slope | +/- |
| Trigger level adjustable | Yes |
| Trigger Source | CH 1, CH 2, EXT |
| Pre/Post trigger | 0 % to 100% |
| Buffer size | 10 K to 64 KB/Channel |
| Sampling selection | Yes |
| Waveform Display | Port or line, waveform average, persistence, intensity |
| Network | Open or Close |
| Vertical mode | CH1, CH2, Dual, ADD |
| Cursor measurement | Yes |
| Math | FFT, addition, subtraction, multiplication, division. |
| Cursor | Frequency, Voltage |
| Data Samples | 10 K to 64 K/Channel |
| Dimension | 8.1 in x 4.7 in x 1.4 in (205 mm x 120 mm x 35 mm) |
