| Bandwidth |
60 MHz, 100 MHz,200 MHz |
| Sample Rate (Real Time) |
1 GS or s, 2 GS or s |
| Channel |
dual + external trigger |
| Horizontal Scale (s or div) |
2 ns/div to 100 s/div, step by 1 to 2 to 51 ns/div to 100 s/div, step by 1 to 2 to 5 |
| Vertical Sensitivity |
2 mV/div to 10 V/div |
| Vertical Resolution (A or D) |
8 bits (2 channels simultaneously) |
| Trigger Mode |
Edge, Video, Alternate, Pulse, and Slope |
| Acquisition Mode |
Normal, Peak Detect, and Average |
| Record Length |
2 M points |
| Waveform Storage |
4 waveforms |
| Waveform Math |
+, -, ×, ÷, FFT |
| Battery |
7.4 V 8000 mAh (optional) |
| Display |
8 in (20.3 cm) color LCD, 640 pixels × 480 pixels |
| Dimensions (W × H × D) |
14.5 in × 7 in × 4.7 in (370 mm × 180 mm × 120 mm) |
| Weight |
4.8 lb (2.20 kg) |
