Features
- Automated display precise flaw location
- Automated switch three staff gauge
- Automated calibration of transducer Zero-point, Angles, Front edge and material Velocity
- Convenient to make and use DACTCG and AVG to evaluate the echo, the curve can be modified and compensated
- 100 independence setup, any criterion can be input freely, we can work in the scene without test block
- The embedded software can be online updated
- Peak Hold and Peak Memory
Technical specification
| Rejection | 0 % to 80 % |
| Pulse displacement | -20 s to 3400 s |
| Sensitivity margin | > 62 dB |
| Temperature | alarm buzzer and LED alarm |
| Sound speed range: | 1000 m/s to 15000 m/s |
| Widening inside the door: | Enlarging echo details for easy analysis of echoes |
| Dynamic range: | ≥36 dB |
| Operating frequency: | 0.5 MHz to 20 MHz |
| Waveform Freeze: | Freezes the waveform displayed on the screen for defect analysis |
| Vertical linearity error: | ≤3.0 % |
| Surface correction: | display circumferential position and depth in real time |
| Horizontal linearity error: | ≤0.1 % |
| Sensitivity margin: | >60 dB |
| Pulse amplitude: | 200 V, 300 V, 400 V, 500 V, 600 V grading selection |
| Crack sounding: | automatic measurement, calculation of crack height |
| Pulse width: | continuously adjustable within 30 ns to 510 ns |
| Weld illustration: | visual display of weld map and defect location |
| Band range: | 0.5 MHz to 10 MHz |
| Automatic calibration: | automatic calibration of probe zero offset and refraction angle, automatic measurement of sound speed |
| Working time: | >10 hrs |
| Plug and socket: | BNC/LEMO |
| Crest memory: | real-time retrieval of the highest wave of defects, recording peak echo |
| Storage function: | 16 GB memory card |
| Number of channels: | 1000 |
| Battery module: | high-capacity lithium battery, online charging |
| Dimensions: | 9.76 in x 5.87 in x 3.67 in (240 mm x 156 mm × 50 mm) |
| weight | 0.76 lb (1.0 kg) |
