Features
- Rugged Housing
- Full screen display function
- Mass storage
- Eliminate Zero Calibration
- Crest Memory
- Automatic gain
- LCD
Technical Specifications
| Working Frequency | 0.5 MHz to 15 MHz |
| Material Sound Velocity | 1000 m/s to 9999 m/s |
| Work Way | Pulse echo, twin crystal |
| Pulse Shift | 0 in to 78.74 in (0 mm to 2000 mm) |
| Probe Zero | 0 µs to 99.99 µs |
| Gain Adjustment | 0 dB to 110 dB, 0.1 dB,1 dB,2 dB,6 dB |
| Vertical Linear Error | ≤3 % |
| Horizontal Linear Error | ≤0.3 % |
| Resolution | ≥32 dB |
| Dynamic Range | ≥30 dB |
| Sensitivity Margin | ≥55 dB (depth 7.87 in Φ2 (200 mm Φ2)) |
| Average Electrical Noise Level | ≤10 % |
| Battery Working Time | >8 hour |
| Power Source | 12 V DC,220 V AC |
| Dimension | 10.63 in x 7.48 in x 2.36 in (270 mm X 190 mm X 60 mm) |
| Weight | 4.41 lb. (2 Kg) |
