Technical Specification
| Output Current | 200 A 100 A |
| Open Circuit Voltage | 10 V |
| Measuring Time | 1 min |
| Resolution | 1 μΩ |
| Humidity | ≤ 85% RH |
| Accuracy | ± (0.5% rdg +2 words) |
| Temperature | 14 °F to 122 °F (-10 °C to 50 °C) |
| Current Measurement | 50 A, 100 A,150 A,200 A |
| Range | 0 mΩ to 100 mΩ (50 A), 0 mΩ to 50 mΩ (100 A)0 mΩ to 20 mΩ (150 A) 0 mΩ to 20 mΩ (200 A) |
| Resolution | 0.1 µΩ At Min. |
| Precision | ± (0.5% ±2) |
| Power Consumption | 1000 W |
| Dimension | 11.81 in x 9.05 in x 8.66 in (300 mm x 230 mm x 220 mm) |
