Features
- High precision PAS alignment system
- Splicing time 6 sec heating time 30 sec
- Fast boot technology
- More than 240 times splicing and heating
- Resist dust, rain, wind, and shock
- Fiber type identify, AUTO splicing mode
- Easy to change electrodes and fiber holder
- High speed USB maintenance via the Internet
Technical Specifications
| Splicing Loss | 0.02 dB (SM), 0.01 dB (MM), 0.04 dB (DS) |
| Typical Splicing Time: | 6 s |
| Typical Splicing Time | 9 s |
| Typo De Connector | Hybrid |
| Language | English French Spanish Italian Portuguese |
| Heat Time | 12 s |
| Return Loss | >60 dB |
| Fiber Diameter | Cladding diameter 80 µm to 150 µm, coating 100 µm to 1000 µm |
| Cleave Length | 250 µm cladding diameters 0.3 in x 0.6 in (8 mm x 16 mm), over 250 µm cladding diameter 16 mm |
| Splicing Programs | Max.100 |
| Heating Programs | Max.30 |
| Heating Time | Heating time |
| Splice Protector | 0.3 in x 2.3 in (10 mm x 60 mm) |
| Splice Image Capture | Max.300 |
| Splice Data Storage | Max.20000 |
| Splice Loss | SM: 0.02dB, MM: 0.01dB, DS: 0.04dB, NZ or NZDS: 0.04dB; BI: 0.02dB |
| Fiber View | Two 300x cameras observation, 4.1 in high-light color screen |
| Operation Condition | Altitude 0 mi x 3.1 mi (0 m x 5000 m),
Humidity 0% to 95%, Temperature –4 °F to 122 °F (Battery -20 ℃ to +40 ℃), Wind velocity up to 15 m/s |
| Storage Condition | Humidity 0% to 95%,
Temperature -40 °F to 176 °F (-40 ℃ to +80 ℃), -4 °F to 104 °F (Battery -20 ℃ to +40 ℃) |
| Fiber Magnification | 300 x for X or Y single axis view, 150 x for both X & Y dual axis view |
| Battery Parameters | 4000 mAh High-capacity battery, more than 240 times splicing and heating |
| Port | High speed USB |
| Electrodes Life | 5000 arc discharges |
| Power Supply | AC 100 V to 240 V, 50 Hz or 60 Hz |
