Overview
Emissions And Stack Fiber Optic Equipment Multifunction FTTR MINI OTDR is used to measure the length, loss, splice quality, and other parameters of various types of optical fiber and optical cable and is widely used in the fields of engineering construction, line maintenance, and emergency rescue testing of optical fiber to the home, metropolitan networks, and secondary backbone communication systems, as well as in the development and production measurement of optical fiber and optical cable.
Features
- 7 I extra-large touchscreen
- 28dB super dynamic range, easily test 80 km fiber optic line.
- 3m ultra-short event blind zone
- One key automatic test
- Automatic s identification of fault information
- Multiple functions integrated into one
- With the light test, easy to test fault problems in fiber optic lines.
- 4600 mA large capacity battery, ultra-long life
Technical Specifications
| Weight | 1.76 lb (0.8 kg), including battery |
| External Dimensions | 6.96 in 4.29 in x 1.45 in (177 mm x 109 mm x 37 mm), excluding soft plastic |
| Maximum Dynamic Range | 28 dB |
| External Interfaces | USB Type C, Micro SD |
| Battery Operating Time | standby ≥ 6 (high brightness) |
| Display | 7 in TFT color LCD (capacitive touch screen) |
| Operating Wavelength | (1310 nm to 1550 nm) ± 20 nm |
| Optical Output | interface FC or UPC, SC or UPC |
