Features
- Auto OTDR, expert OTDR, event map, OPM, Light Source, VFL, Lan cable tracker (Including line finder), Lan cable sequence, Lan cable length, flashlight, optical loss test
- Professional measurement, curve or list or map are displayed simultaneously
- No complex settings, one key test Optical Power Meter supports CW or 270 or 330 or 1 k or 2 kHz frequency identification Light Source supports CW or modulation mode output with adjustable output power
- OVFL and LS can run in the background, multi-task can be operated simultaneously Lan cable tracker of digital radar, stronger anti-jamming ability Lan cable sequence cable length test, up to 0.19 mi (300 m).
Technical Specifications
| Testing Wavelength | 1310 nm or 1550 nm |
| Dynamic Range | 24 dB or 22 dB |
| Event dead zone | 8.20 ft (2.5 m) |
| Test Range | 0.31 mi to 0.06 mi (500 m to 60 km) |
| Display | 4.3-in Multi touch capacitive touching screen |
| Data Interface | USB Type C |
| Internal | 8 GB, >= 20 thousand curves |
| Size | 6.69 in x 4.13 in x 1.73 in (170 mm x 105 mm x 44 mm) |
