Technical Specifications
| Display | 800-pixel x 480-pixel,4.25 in x 2.56 in (108 mm × 65 mm),
> 200 cd/ m2 |
| Protection class | IP 67 |
| Operating temperature | 32 °F to 131 °F (0 °C to 55 °C) |
| Battery | Li-Ion, rechargeable, 6 hours operation time |
| Power adapter / charger | 100 V to 240 V AC, 50 / 60 Hz |
| Probe connector | 2 x Lemo-00 (T/R) |
| PC interface | Mini USB |
| Memory card | SD-Card 16 GB max |
| Reporting | Test report and A-Scan screen shot on SD-Card, Video recording of A-Scan |
| Pulser | 120 V to 300 V, 30 ns to 500 ns, flank < 10 ns, Spike, Square wave option |
| Puls Repetition Frequency | 15 Hz to 2000 Hz |
| Damping | 50 Ohm and 1000 Ohm |
| Receiver | 110 dB dynamic, 0.5 MHz to 18.5 MHz analog bandwidth |
| Filter | BB 1.5 MHz, 2.25 MHz, 4 MHz, 5 MHz, 10 MHz, 13 MHz, 15 MHz |
| Gates | A and B independent, B triggered by A, C option |
| Units | mm, in, µs |
| Options | AWS sizing tool (AWS D1.1), DAC 16 points according to EN 1712, EN 1713, EN 1714, ASTM E164, TCG 110 dB dynamic, DGS sizing tool according to EN 1712, EN 1713, EN 1714, ASTM E164, Data Logger, 3rd gate C, Square Wave Pulser |
| Compliance | EN 55011, EN 61000-6-2: 2011, EN 12668, ASTM E 1324, E317, ANSI/NCSL Z 540-1-1994, MIL-STD 45662A, MIL-STD 2154 |
| Size | 6.9 in x 4.37 in 1.97 in(175 mm x 111 mm x 50 mm) |
| Weight | 1.87 lb. (850 g) with battery |
