Technical Specifications
| Maximum Voltage Exerted Between Any Terminal and Ground, or Between Any Two Terminals | 30 V AC |
| Working Altitude | 1.24 mi (2 km) |
| Storage Altitude | 7.46 mi (12 km) |
| Relative Humidity (Relative Operating Humidity Without Condensation) | 90% to 45% |
| Drop Test Requirements | 39.37 in (1 m) |
| Power Supply | 4 x 5 Gauge NEDA 15A IEC LR6 Batteries |
| DC mA Measurements | Range 0 mA to 24 mA
Resolution 0.001 mA Accuracy (Percentage of Reading + Count) 0.010% + 2 μA, Temperature Coefficient ± (0.002% of Reading + 0.002% of Range) / °C <0 °F or >82.4 °F (<18 °C or >28 °C) |
| Measurement and Output (Millivolts) | Range -10 mV to 75 mV
Resolution 0.01 mV Accuracy (Percentage of Reading + Count) 0.015% + 10 μA, Temperature Coefficient ± (0.002% of Reading + 0.002% of Range) / °C <0 °F or >82.4 °F (<18 °C or >28 °C) |
| Loop Power Supply | Open-Circuit Voltage 24 V ±10%
Load Circuit Voltage 18 V Min. at 20 mA Temperature Coefficient ± (0.002% of Reading + 0.002% of Range) / °C <0 °F or >82.4 °F (<18 °C or >28 °C) |
| Operating Temperature | 14 °F to 122 °F (-10 °C to 50 °C) |
| Storage Temperature | -22 °F to 140 °F (-30 °C to 60 °C) |
| Dimensions (H x W x L) | 2.07 in x 3.31 in x 7.42 in (52.5 mm x 84 mm x 188.5 mm) |
| Weight | 1.14 lb (515 g) |
